What we offer: 1) Good quality control 2) Highly competitive prices 3) state-of-art technology products 4) Best professional team of lifestyle consumer electronics. 5) Smooth communication 6) Effective OEM&ODM service
-
Highlight
3OZ one stop pcb assembly
,2OZ one stop pcb assembly
,1OZ one stop pcba
-
Base MaterialFR-4, Glass Epoxy, FR4 High Tg, Rohs Compliant
-
Copper Thickness1/2OZ 1OZ 2OZ 3OZ
-
Board Thickness0.4~4.0mm
-
Min. Hole Size0.01'',0.25mm.or 10 Mil
-
Min. Line Width0.006'' Or 0.15mm
-
Min. Line Spacing4 Mil
-
Surface FinishingHASL, Lead Free, OSP, ENIG Etc.
-
Order Quantity1-500,000
-
Number Of Layer1,2,4,6,up To 22 Layers
-
PCB TypeHard, Flexible, Rigid-flexible
-
Max PCB Dimensions20inch*20inch Or 500mm*500mm
-
Thickness Tolerance± 10%
-
Copper Thickness Tolerance± 0.25oz
-
Solder MaskGreen, Red, White, Yellow, Blue, Black, Etc
-
Silk ScreenWhite, Yellow, Black, Or Negative, Etc
-
SMT Jointing Min. Space0201mm
-
QFP SpacePitch 0.3mm
-
PortYantian, Shekou, Hongkong
-
Place of OriginGuangdong, China
-
Brand NameCustomized
-
Model NumberLUX002032
-
Price$20.00/pieces 1-10 pieces
-
Packaging DetailsThe goods are packed in anti-plastic bag or individual box, will be packed into corrugated packaging, made of five-layered corrugated carton.
-
Supply Ability1000 Piece/Pieces per Day
Printed Circuit Board Assembly Gerber File BOM List One Stop PCBA Custom
PCBA PCB Printed Circuit Board Assembly Gerber File BOM List One-Stop PCBA PCB Circuit Board Custom PCBA PCB Board
| PCB Technical Specification | |||||
| Order quantity | 1-500,000 | ||||
| Number of layer | 1,2,4,6,up to 22 layers | ||||
| Board material | FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc | ||||
| PCB type | Hard, flexible, rigid-flexible | ||||
| Shape | Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc | ||||
| Max PCB dimensions | 20inch*20inch or 500mm*500mm | ||||
| Board thickness | 0.4~4.0mm | ||||
| Thickness tolerance | ± 10% | ||||
| Copper thickness | 1/2OZ 1OZ 2OZ 3OZ | ||||
| Copper thickness tolerance | ± 0.25oz | ||||
| Solder mask | Green, red, white, yellow, blue, black, etc | ||||
| Silk screen | White, yellow, black, or negative, etc | ||||
| Silk screen min line width | 0.006'' or 0.15mm | ||||
| Surface finish | HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc | ||||
| Min drill hole diameter | 0.01'',0.25mm.or 10 mil | ||||
| PCB cutting | Shear,V-score,tab-routed | ||||
| PCB Assembly Capabilities | |||||
| SMT Jointing Min. Space | 0201mm | ||||
| QFP Space | Pitch 0.3mm | ||||
| Min. Package | 201 | ||||
| Min. Size | 2*2 inch(50*50mm) | ||||
| Max. Size | 14*22 inch(350*550mm) | ||||
| Placement Precision | ±0.01mm | ||||
| Placement Precision | QFP, SOP, PLCC, BGA | ||||
| Placement Capability | 0805, 0603, 0402, 0201 | ||||
| PCB Lead time (workday(s)) | |||||
| Single, Double-sided | 4 layer | 6 layer | Over 8 layer | HDI | |
| Sample Lead time (Normal) | 4~5 days | 6~7 days | 7~8 days | 10~12 days | 10~12 days |
| Sample Lead time (Faster) | 2~3 days | 3~5 days | 6 days | 6~7 days | 12 days |
| Mass production lead time | 7~10 days | 10~14 days | 13-14 days | 16 days | 20 days |
| PCB Assembly Lead time | |||||
| Sample Lead time | PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties. | ||||
| Mass production lead time | PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties. | ||||
