Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service

Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service

Products - 1 Layer PCB
  • High Light

    0.01'' pcb circuit board assembly

    ,

    PMU pcb circuit board assembly

    ,

    0.15mm pcba assembly service

  • Base Material
    FR-4, Glass Epoxy, FR4 High Tg, Rohs Compliant
  • Copper Thickness
    1/2OZ 1OZ 2OZ 3OZ
  • Board Thickness
    0.4~4.0mm
  • Min. Hole Size
    0.01'',0.25mm.or 10 Mil
  • Min. Line Width
    0.006'' Or 0.15mm
  • Min. Line Spacing
    4 Mil
  • Surface Finishing
    HASL, OSP, ENIG, Lead Free
  • Order Quantity
    1-500,000
  • Number Of Layer
    1,2,4,6,up To 22 Layers
  • PCB Type
    Hard, Flexible, Rigid-flexible
  • Max PCB Dimensions
    20inch*20inch Or 500mm*500mm
  • Thickness Tolerance
    ± 10%
  • Copper Thickness Tolerance
    ± 0.25oz
  • Solder Mask
    Green, Red, White, Yellow, Blue, Black, Etc
  • Silk Screen
    White, Yellow, Black, Or Negative, Etc
  • SMT Jointing Min. Space
    0201mm
  • QFP Space
    Pitch 0.3mm
  • Place of Origin
    Guangdong, China
  • Model Number
    APP0001
  • Price
    $20.00/pieces 1-20 pieces
  • Packaging Details
    The goods are packed in anti-plastic bag or individual box, will be packed into corrugated packaging, made of five-layered corrugated carton.

Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service

  • Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service
  • Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service
  • Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service
  • Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service
  • Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service
  • Professional Air Purifier PMU PCB Circuit Board Assembly DIP PCBA Assembly Service
Get Price Contact Now



Professional Air Purifier PMU PCB Circuit Boards DIP PCBA Assembling Service Pcba Manufacturer

Products Description
PCB Technical Specification





Order quantity
1-500,000




Number of layer
1,2,4,6,up to 22 layers




Board material
FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc




PCB type
Hard, flexible, rigid-flexible




Shape
Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc




Max PCB dimensions
20inch*20inch or 500mm*500mm




Board thickness
0.4~4.0mm




Thickness tolerance
± 10%




Copper thickness
1/2OZ 1OZ 2OZ 3OZ




Copper thickness tolerance
± 0.25oz




Solder mask
Green, red, white, yellow, blue, black, etc




Silk screen
White, yellow, black, or negative, etc




Silk screen min line width
0.006'' or 0.15mm




Surface finish
HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc




Min drill hole diameter
0.01'',0.25mm.or 10 mil




PCB cutting
Shear,V-score,tab-routed




PCB Assembly Capabilities





SMT Jointing Min. Space
0201mm




QFP Space
Pitch 0.3mm




Min. Package
201




Min. Size
2*2 inch(50*50mm)




Max. Size
14*22 inch(350*550mm)




Placement Precision
±0.01mm




Placement Precision
QFP, SOP, PLCC, BGA




Placement Capability
0805, 0603, 0402, 0201




PCB Lead time (workday(s))






Single, Double-sided
4 layer
6 layer
Over 8 layer
HDI
Sample Lead time (Normal)
4~5 days
6~7 days
7~8 days
10~12 days
10~12 days
Sample Lead time (Faster)
2~3 days
3~5 days
6 days
6~7 days
12 days
Mass production lead time
7~10 days
10~14 days
13-14 days
16 days
20 days
PCB Assembly Lead time





Sample Lead time
PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties.




Mass production lead time
PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties.
