Multilayered OEM/ODM Customized Pcba Design Board Pcba Assembly Circuit Pcb
|
PCB Technical Specification
|
|
|
|
|
|
|||||
|
Order quantity
|
1-500,000
|
|
|
|
|
|||||
|
Number of layer
|
1,2,4,6,up to 22 layers
|
|
|
|
|
|||||
|
Board material
|
FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
|
|
|
|
|
|||||
|
PCB type
|
Hard, flexible, rigid-flexible
|
|
|
|
|
|||||
|
Shape
|
Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
|
|
|
|
|
|||||
|
Max PCB dimensions
|
20inch*20inch or 500mm*500mm
|
|
|
|
|
|||||
|
Board thickness
|
0.4~4.0mm
|
|
|
|
|
|||||
|
Thickness tolerance
|
± 10%
|
|
|
|
|
|||||
|
Copper thickness
|
1/2OZ 1OZ 2OZ 3OZ
|
|
|
|
|
|||||
|
Copper thickness tolerance
|
± 0.25oz
|
|
|
|
|
|||||
|
Solder mask
|
Green, red, white, yellow, blue, black, etc
|
|
|
|
|
|||||
|
Silk screen
|
White, yellow, black, or negative, etc
|
|
|
|
|
|||||
|
Silk screen min line width
|
0.006'' or 0.15mm
|
|
|
|
|
|||||
|
Surface finish
|
HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc
|
|
|
|
|
|||||
|
Min drill hole diameter
|
0.01'',0.25mm.or 10 mil
|
|
|
|
|
|||||
|
PCB cutting
|
Shear,V-score,tab-routed
|
|
|
|
|
|||||
|
PCB Assembly Capabilities
|
|
|
|
|
|
|||||
|
SMT Jointing Min. Space
|
0201mm
|
|
|
|
|
|||||
|
QFP Space
|
Pitch 0.3mm
|
|
|
|
|
|||||
|
Min. Package
|
201
|
|
|
|
|
|||||
|
Min. Size
|
2*2 inch(50*50mm)
|
|
|
|
|
|||||
|
Max. Size
|
14*22 inch(350*550mm)
|
|
|
|
|
|||||
|
Placement Precision
|
±0.01mm
|
|
|
|
|
|||||
|
Placement Precision
|
QFP, SOP, PLCC, BGA
|
|
|
|
|
|||||
|
Placement Capability
|
0805, 0603, 0402, 0201
|
|
|
|
|
|||||
|
PCB Lead time (workday(s))
|
|
|
|
|
|
|||||
|
|
Single, Double-sided
|
4 layer
|
6 layer
|
Over 8 layer
|
HDI
|
|||||
|
Sample Lead time (Normal)
|
4~5 days
|
6~7 days
|
7~8 days
|
10~12 days
|
10~12 days
|
|||||
|
Sample Lead time (Faster)
|
2~3 days
|
3~5 days
|
6 days
|
6~7 days
|
12 days
|
|||||
|
Mass production lead time
|
7~10 days
|
10~14 days
|
13-14 days
|
16 days
|
20 days
|
|||||
|
PCB Assembly Lead time
|
|
|
|
|
|
|||||
|
Sample Lead time
|
PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties.
|
|
|
|
|
|||||
|
Mass production lead time
|
PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties.
|
|
|
|
|
|||||
