Multilayered OEM Printed Circuit Board Assembly PCBA 0.5oz 1oz 2oz 3oz

Products - 1 Layer PCB

High Light

Multilayered printed circuit board assembly pcba
,
0.5oz printed circuit board assembly pcba
,
3oz assembled circuit board
Base Material

FR-4, Glass Epoxy, FR4 High Tg, Rohs Compliant
Copper Thickness

1/2OZ 1OZ 2OZ 3OZ
Board Thickness

0.4~4.0mm
Min. Hole Size

0.01'',0.25mm.or 10 Mil
Min. Line Width

0.006'' Or 0.15mm
Min. Line Spacing

4 Mil
Surface Finishing

HASL, Lead Free, OSP, ENIG Etc.
Order Quantity

1-500,000
Number Of Layer

1,2,4,6,up To 22 Layers
PCB Type

Hard, Flexible, Rigid-flexible
Max PCB Dimensions

20inch*20inch Or 500mm*500mm
Thickness Tolerance

± 10%
Copper Thickness Tolerance

± 0.25oz
Solder Mask

Green, Red, White, Yellow, Blue, Black, Etc
Silk Screen

White, Yellow, Black, Or Negative, Etc
SMT Jointing Min. Space

0201mm
QFP Space

Pitch 0.3mm
Port

Yantian, Shekou, Hongkong
Place of Origin

Guangdong, China
Brand Name

Customized
Model Number

LUX0069
Price

$20.00/pieces 1-10 pieces
Packaging Details

The goods are packed in anti-plastic bag or individual box, will be packed into corrugated packaging, made of five-layered corrugated carton.
Supply Ability

1000 Piece/Pieces per Day

Multilayered OEM Printed Circuit Board Assembly PCBA 0.5oz 1oz 2oz 3oz

Name: Multilayered OEM Printed Circuit Board Assembly PCBA 0.5oz 1oz 2oz 3oz
Brand: Customized
SKU: LUX0069
Price: 20.00 USD
Availability: InStock
Rating: 4.6 (167 reviews)

button button

Get Price Contact Now

Multilayered OEM Customized Pcba Design Board PCBA Assembly Circuit PCB

Products Description

PCB Technical Specification
Order quantity	1-500,000
Number of layer	1,2,4,6,up to 22 layers
Board material	FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
PCB type	Hard, flexible, rigid-flexible
Shape	Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
Max PCB dimensions	20inch20inch or 500mm500mm
Board thickness	0.4~4.0mm
Thickness tolerance	± 10%
Copper thickness	1/2OZ 1OZ 2OZ 3OZ
Copper thickness tolerance	± 0.25oz
Solder mask	Green, red, white, yellow, blue, black, etc
Silk screen	White, yellow, black, or negative, etc
Silk screen min line width	0.006'' or 0.15mm
Surface finish	HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc
Min drill hole diameter	0.01'',0.25mm.or 10 mil
PCB cutting	Shear,V-score,tab-routed
PCB Assembly Capabilities
SMT Jointing Min. Space	0201mm
QFP Space	Pitch 0.3mm
Min. Package	201
Min. Size	22 inch(5050mm)
Max. Size	1422 inch(350550mm)
Placement Precision	±0.01mm
Placement Precision	QFP, SOP, PLCC, BGA
Placement Capability	0805, 0603, 0402, 0201
PCB Lead time (workday(s))
	Single, Double-sided	4 layer	6 layer	Over 8 layer	HDI
Sample Lead time (Normal)	4~5 days	6~7 days	7~8 days	10~12 days	10~12 days
Sample Lead time (Faster)	2~3 days	3~5 days	6 days	6~7 days	12 days
Mass production lead time	7~10 days	10~14 days	13-14 days	16 days	20 days
PCB Assembly Lead time
Sample Lead time	PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties.
Mass production lead time	PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties.

Company Profile

Shenzhen Oriental FastAssembly Electronic Co., Ltd.

Oriental FastAssembly Ltd. Is a PCBA manufacturer founded in year 2001, locating in Longtian district of Pingshan, Shenzhen, specializing in turnkey solution including electronics design, PCB fabrication, SMT and PCB assembly, Components sourcing, molding, metals and plastics, cables & final assembly, logistics and other value-added services etc. We’ve provide Electronic Contract Manufacturing service for products of Industrial Control, Consumer Electronics, LED/Lightning, Energy and Game Devices. Our factory is ISO9001 qualified. We have cooperated with clients around China for a long time. At the same time, our business has been expanded to Asia, Europe and America since 2005. Our core business is PCB assembly. We can provide services also including Electronic design, PCB Copy and Clone, PCB fabrication, Component sourcing, Products final assembly, Plastic Moldings & Metals, Logistics and Value-added service.

What we offer: 1) Good quality control 2) Highly competitive prices 3) state-of-art technology products 4) Best professional team of lifestyle consumer electronics. 5) Smooth communication 6) Effective OEM&ODM service

Production Line

Certifications

Cooperative

Packing & Delivery

FAQ

Q1: What files needed for PCBA quotation? A: PCB files(gerber),BOM list, XY data(pick-N-place).

Q2: MOQ and what's OFAL fatest delivery time? A:1pc. Both samples and mass production can be supported by OFAL. Bare PCB prototye: 2 layers, 24 hours 4 layers, 48 hours 6~8 layers, 72 hours PCBA(PCB Assembly): QTY<30pcs, 1 day QTY 30~100pcs, 2 days QTY 100~1000pcs, 5 days Q3: For PCB quotation, what files format do OFAL need? A: Gerber, protell 99SE, DXP, PADS 9.5, AUTOCAD, CAM350 are OK. Q4: How OFAL test PCB and PCBA boards? A: SPI, AOI, X-ray, FQC for PCBA(PCB Assembly),AOI, Fly probe testing, Test fixture testing, FQC etc for bare PCB. Q5: Can you do PCB or circuit design? A: Yes, we have design team including software, hardware and structure engineers. We can supply customized design service. Q6: Which payment terms do OFAL accept? A: TT, western union, money gram, Paypal, we also accept L/C.
