16C550 Boiler Board PCB 1 Layer FR4 Glass Epoxy 4 Mil

Products - 1 Layer PCB

High Light

Boiler Board pcb 1 layer
,
pcb 1 layer FR4
,
4 Mil board assembly
Base Material

FR-4, Glass Epoxy, FR4 High Tg, Rohs Compliant
Copper Thickness

1/2OZ 1OZ 2OZ 3OZ
Board Thickness

0.4~4.0mm
Min. Hole Size

0.01'',0.25mm.or 10 Mil
Min. Line Width

0.006'' Or 0.15mm
Min. Line Spacing

4 Mil
Surface Finishing

HASL, OSP, ENIG, Lead Free
Order Quantity

1-500,000
Number Of Layer

1,2,4,6,up To 22 Layers
PCB Type

Hard, Flexible, Rigid-flexible
Max PCB Dimensions

20inch*20inch Or 500mm*500mm
Thickness Tolerance

± 10%
Copper Thickness Tolerance

± 0.25oz
Solder Mask

Green, Red, White, Yellow, Blue, Black, Etc
Silk Screen

White, Yellow, Black, Or Negative, Etc
SMT Jointing Min. Space

0201mm
QFP Space

Pitch 0.3mm
Place of Origin

Guangdong, China
Model Number

16C550
Price

$4.80/pieces 1-20 pieces
Packaging Details

The goods are packed in anti-plastic bag or individual box, will be packed into corrugated packaging, made of five-layered corrugated carton.

16C550 Boiler Board PCB 1 Layer FR4 Glass Epoxy 4 Mil

Name: 16C550 Boiler Board PCB 1 Layer FR4 Glass Epoxy 4 Mil
Brand: 16C550 Boiler Board PCB 1 Layer FR4 Glass Epoxy 4 Mil
SKU: 16C550
Price: 4.80 USD
Availability: InStock
Rating: 5 (142 reviews)

button button

Get Price Contact Now

Guaranteed Quality Customized 16C550 Boiler Board Circuit Board PCBA Assembly

Products Description

PCB Technical Specification
Order quantity	1-500,000
Number of layer	1,2,4,6,up to 22 layers
Board material	FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
PCB type	Hard, flexible, rigid-flexible
Shape	Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
Max PCB dimensions	20inch20inch or 500mm500mm
Board thickness	0.4~4.0mm
Thickness tolerance	± 10%
Copper thickness	1/2OZ 1OZ 2OZ 3OZ
Copper thickness tolerance	± 0.25oz
Solder mask	Green, red, white, yellow, blue, black, etc
Silk screen	White, yellow, black, or negative, etc
Silk screen min line width	0.006'' or 0.15mm
Surface finish	HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc
Min drill hole diameter	0.01'',0.25mm.or 10 mil
PCB cutting	Shear,V-score,tab-routed
PCB Assembly Capabilities
SMT Jointing Min. Space	0201mm
QFP Space	Pitch 0.3mm
Min. Package	201
Min. Size	22 inch(5050mm)
Max. Size	1422 inch(350550mm)
Placement Precision	±0.01mm
Placement Precision	QFP, SOP, PLCC, BGA
Placement Capability	0805, 0603, 0402, 0201
PCB Lead time (workday(s))
	Single, Double-sided	4 layer	6 layer	Over 8 layer	HDI
Sample Lead time (Normal)	4~5 days	6~7 days	7~8 days	10~12 days	10~12 days
Sample Lead time (Faster)	2~3 days	3~5 days	6 days	6~7 days	12 days
Mass production lead time	7~10 days	10~14 days	13-14 days	16 days	20 days
PCB Assembly Lead time
Sample Lead time	PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties.
Mass production lead time	PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties.
