Connectors For Surface Mounted Assembly With Red Solder Mask Color
Surface Mount PCB Assembly, also known as Printed Circuit Board Assembly or Surface Mount Technology Assembly, is a highly advanced, reliable and cost-effective form of electronic component assembly. It is used for a wide variety of applications, from consumer electronics to aerospace and automotive components. The process involves mounting components onto the printed circuit board (PCB) using a reflow soldering technique, with the components placed on the surface of the board and connected via copper traces. This process ensures that the components are securely fastened to the board and that there are no loose connections.
The components used in SMT PCB Assembly are typically small surface mount components, such as capacitors, resistors, transistors, and integrated circuits. These components are placed on the printed circuit board in a predetermined pattern, and then soldered to the board using reflow soldering. The components can be of various sizes and shapes, with the most common being through-hole, chip scale, and flip chip components. The components are usually attached to the board using solder paste, which is then heated to melt the solder and attach the components to the board.
The soldering process requires a high level of precision and accuracy, as well as a consistent temperature to ensure a strong connection between the components and the board. The components must also be carefully inspected to ensure that they meet the highest quality standards. After the soldering process is completed, the board is tested using various methods, such as automated optical inspection (AOI), X-ray, flying probe, in-circuit test (ICT), and functional test (FCT).
SMT PCB Assembly can be manufactured using a variety of materials, such as FR-4, FR-1, CEM-1, CEM-3, aluminum, and Rogers. The surface finish of the board can also be customized to meet the customer’s needs, with the most popular options being HASL, ENIG, OSP, immersion silver, and immersion tin.
SMT PCB Assembly, produced by KZX, is a high-precision Surface Mount Technique (SMT) assembly that offers superior performance and reliability. This product is certified by 25020001470ROS and is available for a minimum order quantity of 10 pieces. KZX offers competitive pricing and quick delivery time, subject to order status. Payment terms include T/T, L/C, Paypal, western union, among others. KZX has 3 SMT production lines, with the ability to produce boards with thickness from 0.2 to 6.0 mm. The solder mask colors available are green, blue, white, black, yellow, and red. Silk screen colors include white, black, and yellow. This SMT PCB Assembly can be used for Passive Components, Connectors, ICs, BGA, QFN, and other components.
KZX's SMT PCB Assembly is designed for high-end applications, such as automotive, medical, industrial, consumer electronics, and other industries. The product is optimized for circuit board performance and reliability. It is suitable for both low-volume and high-volume production. KZX provides customers with comprehensive services, including prototype design, design for manufacturability, and quality control. With its comprehensive solutions, KZX's SMT PCB Assembly is the ideal choice for manufacturers who require the highest quality and performance.
Surface Mounted Assembly, Surface Mounted Printed Circuit Board Assembly, Surface Mounting Assembly, Surface Mount Technology.
We provide technical support and services for SMT PCB assembly. Our experienced and knowledgeable professionals can help you with any questions or concerns you may have about the assembly process. We provide technical advice, troubleshooting, and guidance to ensure your assembly is successful. We can also provide custom engineering and design services to meet your specific needs.
We use the latest technology in the assembly process, including automated pick-and-place machines and reflow ovens. We also use advanced test equipment and inspection systems to ensure the highest quality of assemblies. Our team of experts can provide comprehensive support throughout the entire assembly process.
We have a dedicated customer service team that is available 24/7 to answer any questions or concerns you may have. We also offer a variety of online resources, including technical articles, tutorials, and videos, to help you learn more about SMT PCB assembly.
If you have any questions or concerns, please don't hesitate to contact us. Our experienced team is here to help you every step of the way.
SMT PCB Assembly Packaging and Shipping:
Packaging: The products are packed in special antistatic bags, with foam protection inside the box to ensure the safety of products during transportation.
Shipping: The products will be shipped via international express delivery and arrive in 3-7 days.
Our products are sold all over the world, you can rest assured.
