Immersion Tin Surface Finish SMT PCB Assembly For 0.2-6.0mm Board Thickness
SMT PCB Assembly is a comprehensive service for the electronic industry, providing high-quality surface mounted assembly services for various components such as passive components, connectors, ICs, BGA, QFN, etc. The board thickness ranges from 0.2mm to 6.0mm, and the surface finishes include HASL, ENIG, OSP, immersion silver, and immersion tin to meet different requirements. In addition, the materials used are FR-4, FR-1, CEM-1, CEM-3, aluminum and rogers. Test methods include AOI, X-ray, flying probe, ICT, and FCT. As a professional surface mount assembly service provider, we are committed to providing customers with reliable and cost-effective surface mount assembly services.
We can provide customers with advanced surface mount assembly services which include surface mount components, surface mount PCB assembly, reflow soldering, wave soldering, selective soldering, automated soldering, robotic soldering and other surface mount assembly services. We are committed to providing customers with high-quality and cost-effective surface mount assembly services. We also provide comprehensive testing services such as testing for continuity, dielectric strength, insulation resistance, etc. to ensure the quality of the assembly.
At SMT PCB Assembly, our goal is to provide our customers with the best surface mount assembly services. We have a team of experienced engineers and technicians who have extensive experience in PCB assembly and can provide customers with reliable and cost-effective surface mount assembly services. We have the latest equipment and advanced technology to ensure that all products meet the highest standards of quality and reliability.
Parameter | Value |
---|---|
Product Type | Surface Mount Technique Assembly (SMT) Surface Mount Technology Assembly (SMT) Printed Circuit Board Mounting Assembly (PCB) |
Test | Automated Optical Inspection (AOI) X-Ray Inspection Flying Probe Test In-Circuit Test (ICT) Functional Test (FCT) |
Silk Screen Color | White Black Yellow |
Material Type | FR-4 FR-1 CEM-1 CEM-3 Aluminum Rogers |
Surface Finish | Hot Air Solder Level (HASL) Electroless Nickel Immersion Gold (ENIG) Organic Solder Potect (OSP) Immersion Silver Immersion Tin |
Board Thickness | 0.2mm - 6.0mm |
Solder Mask Color | Green Blue White Black Yellow Red |
Components | Passive Components Connectors Integrated Circuits (ICs) Ball Grid Array (BGA) Quad Flat No-lead (QFN) |
KZX SMT PCB Assembly (Model Number: KZX2023120502), is one of the most reliable and advanced printed circuit board mounting assemblies that can provide customers with excellent surface mounting assembly performance. It is a brand of KZX with a certification of 25020001470ROS, and it has a minimum order quantity of 10 pieces. The price of this product is negotiable. Customers can choose the most suitable packing method for their products. The delivery time of this product is subject to order status. The payment terms include T/T, L/C, Paypal, western union, etc. KZX has 3 PCB SMT lines with an excellent production capacity. The silk screen color of this product can be white, black, or yellow. The board thickness is from 0.2 mm to 6.0 mm, and the material can be FR-4, FR-1, CEM-1, CEM-3, Aluminum, or Rogers. This product is suitable for SMT PCB assembly, and it can provide customers with a wide range of components, including passive components, connectors, ICs, BGA, and QFN. This product is specially designed for surface mounting assembly, surface mounted assembly, and surface mount assembly.
KZX offers customized Surface Mount Technology Assembly (SMT Assembly) services, Surface Mounting Assembly services, Surface Mounted Assembly services, and PCB Assembly services. We use advanced SMT assembly equipment and have over 10 years of experience in SMT assembly. Our experts are well trained and have extensive knowledge in all aspects of SMT assembly. We offer our customers the highest quality SMT assembly services and the most competitive prices.
We offer comprehensive technical support and service for SMT PCB Assembly. Our qualified and experienced team is available to assist you with all your needs, from design and prototyping through to production and testing. We provide detailed information about the process and equipment, as well as troubleshooting advice. We can also provide custom solutions to fit your unique requirements.
We are equipped with the latest technology and tools for SMT PCB Assembly, including X-Ray Inspection, Automated Optical Inspection (AOI) and Automated Solder Paste Inspection (SPI). Our experienced technicians can ensure that your assembly is of the highest quality, with the highest yield possible.
We also provide after-sales service and support. Our experienced technicians are available for training, maintenance, repairs and upgrades. We also offer a comprehensive warranty on all our products.
When shipping SMT PCB Assembly products, we package the products carefully. We use ESD Shielding Bags to protect the products from any possible electrostatic discharge during the shipping process. We also use bubble wrap and thick cardboard boxes to cushion the products and protect them from any potential impacts during transit. Lastly, we seal the boxes with shipping tape to ensure that the products remain secure throughout the shipping process.
