SMT PCB Assembly With FR-4 Material For Surface Mounted Printed Circuit Board Assembly
SMT PCB Assembly is an essential part of printed circuit board (PCB) manufacturing. It involves the assembly of components such as passive components, connectors, integrated circuits (ICs), ball grid arrays (BGAs), and quad flat no-leads (QFNs) onto printed circuit boards. This process is typically performed by automated machines using surface mount technology (SMT). The components are placed on the PCB using a specialized pick and place machine, and then soldered using a combination of soldering paste and reflow ovens. To ensure quality, automated optical inspection (AOI), x-ray inspection, flying probe testing, in-circuit testing (ICT) and functional testing (FCT) are often incorporated into the production process.
The materials used in SMT PCB assembly vary depending on the application, but typically include fiberglass-reinforced plastics such as FR-4 and FR-1, copper-clad laminates like CEM-1 and CEM-3, aluminum, and Rogers. The assembly process also includes printing of silk screen colors including white, black, and yellow. Printed circuit board mounting assembly is a specialized form of SMT PCB assembly that involves the use of special mounting techniques to secure the PCBs in place.
| Parameters | Details |
|---|---|
| Product Type | Surface Mount Technique Assembly (SMT PCB Assembly) |
| Board Thickness | 0.2-6.0mm |
| Solder Mask Color | Green, Blue, White, Black, Yellow, Red |
| Material Type | FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Immersion Tin |
| Test | AOI, X-Ray, Flying Probe, ICT, FCT |
| Components | Passive Components, Connectors, ICs, BGA, QFN |
| Silk Screen Color | White, Black, Yellow |
KZX's SMT PCB Assembly is a high quality, reliable and cost-effective Surface Mounted Printed Circuit Board Assembly solution that complies with all the standards of the Surface Mount Technology Assembly and Printed Circuit Board Mounting Assembly. With KZX's Model Number KZX2023120502 and Guangdong, China's 25020001470ROS Certification, KZX's SMT PCB Assembly offers a minimum order quantity of 10 pieces and a price that is negotiable, with customer specified packing and delivery time that is subject to order status. Payment terms include T/T, L/C, Paypal, western union etc. The Supply Ability of the product is 3 PCB SMT lines with components including Passive Components, Connectors, ICs, BGA, QFN. The solder mask color is available in Green, Blue, White, Black, Yellow, Red and board thickness ranges from 0.2-6.0mm. The Silk Screen Color is available in White, Black, Yellow.
Brand Name: KZX
Model Number: KZX2023120502
Place of Origin: Guangdong, China
Certification: 25020001470ROS
Minimum Order Quantity: 10 piece
Price: Price negotiation
Packaging Details: Customer specified packing
Delivery Time: Subject to order status
Payment Terms: T/T, L/C,Paypal,western union etc
Supply Ability: 3 PCB SMT lines
Product Type: Printed Circuit Board Mounting Assembly, Surface Mounted Assembly, Surface Mount Technology Assembly
Test: AOI, X-Ray, Flying Probe, ICT, FCT
Silk Screen Color: White, Black, Yellow
Surface Finish: HASL, ENIG, OSP, Immersion Silver, Immersion Tin
Solder Mask Color: Green, Blue, White, Black, Yellow, Red
