High Performance Multi Layer PCB Assembly With Min Hole Size 0.25mm

Product Description:

Our Multilayer PCB Assembly is the perfect choice for high-level circuit board assembly needs. It has 8 Layer PCB, 4 Layer PCB, and other layer options up to 20 layers, with copper thicknesses of 1/2OZ, 1OZ, 2OZ, and 3OZ. Our boards have a minimum trace/space of 4 Mil, and we guarantee a lead time of 7-15 days for all orders. Our Multilayer PCB Assembly is perfect for high-level circuit board assembly needs, and is the only choice for those who require optimal performance and superior quality.

Features:

• Product Name: Multilayer PCB Assembly
• Board Thickness: 0.4-3.0mm
• Layer Count: 1-20, including 6 layer PCB
• Min Trace/Space: 4 Mil
• Silkscreen Color: White, Black, Yellow
• Board Size: Max 500mm*500mm
• Flex PCB Assembly
• FR4 Multilayer PCB
• HDI PCB Assembly

Technical Parameters:

Applications:

KZX is a leading supplier of custom PCB assembly services and multilayer PCB assembly services. Our state-of-the-art automatic surface mount and through-hole assembly equipment ensures the highest quality and lowest cost for all of our customers. Our 8 layer PCBs are among the best in the industry and are certified with the 25020001470ROS certification.

Our KZX2023120514 model of multilayer PCB assembly offers provides excellent performance and reliability in a variety of applications. Our minimum order quantity is 10 pieces and the price is negotiable. We can customize the packing according to the customer's needs. Delivery time is subject to order status. Payment terms include T/T, L/C, Paypal, western union, etc. Our production capacity is 3 PCB SMT lines.

Our multilayer PCB assembly has excellent characteristics such as board thickness of 0.4-3.0mm, board size of maximum 500mm*500mm, minimum trace/space of 4 Mil, minimum hole size of 0.01'',0.25mm or 10 Mil. We use top-of-the-line materials such as FR4, High TG FR4, Halogen Free, Aluminum, Rogers, and Teflon.

KZX prides itself in providing the highest quality custom PCB assembly and multilayer PCB assembly services in the industry. With our certification, competitive price, reliable delivery and excellent customer service, you can trust KZX for your 8 layer PCB and communication PCB assembly needs.

Customization:

Packing and Shipping:

Packaging and Shipping for Multilayer PCB Assembly:

• PCB assemblies are placed in anti-static bags.
• Bags are sealed with a tape and labeled with customer name and part number.
• Bags are placed in custom made shipping boxes.
• Boxes are labeled with customer name, part number, quantity and other relevant information.
• Boxes are securely sealed with tape.
• Boxes are shipped via FedEx, UPS, or other reliable courier services.
