Rogers Surface Mounted Multilayer PCB Assembly 0.2-6.0mm

Product Description:

SMT PCB Assembly is a surface mounted printed circuit board assembly technology designed to mount electronic components on the surface of a printed circuit board (PCB) without the need for through-hole mounting. It is a cost-effective and efficient way to manufacture PCBs to meet the needs of various applications. SMT PCB Assembly uses solder mask in various colors such as green, blue, white, black, yellow, and red to protect the PCB from short circuits and oxidation. The material used for the PCB can be FR-4, FR-1, CEM-1, CEM-3, aluminum, and Rogers, allowing for flexible PCB design and production. Components such as passive components, connectors, ICs, BGA, and QFN can be used with this technology. The silk screen color also can be white, black, or yellow. SMT PCB Assembly is widely used in industries such as automotive, aerospace, and medical.

Features:

• Product Name: SMT PCB Assembly
• Surface Finish: HASL, ENIG, OSP, Immersion Silver, Immersion Tin
• Components: Passive Components, Connectors, ICs, BGA, QFN
• Product Type: Surface Mounted Assembly, Printed Circuit Board Assembly, Surface Mounted Printed Circuit Board Assembly
• Solder Mask Color: Green, Blue, White, Black, Yellow, Red
• Material Type: FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers

Technical Parameters:

Applications:

KZX offers SMT PCB Assembly with the brand name KZX and model number KZX2023120502. The product is manufactured in Guangdong, China and certified with 25020001470ROS. The minimum order quantity for the product is 10 pieces. The price of the product is negotiable. The product is packed in customer specified packing and the delivery time is subject to order status. The payment terms are T/T, L/C,Paypal,western union etc. The company has 3 PCB SMT lines for the assembly. The board thickness for the product is 0.2-6.0mm and components used in the assembly are passive components, connectors, ICs, BGA, QFN. The colors for the silk screen are white, black and yellow. The surface finish used in the assembly are HASL, ENIG, OSP, Immersion Silver and Immersion Tin.

The SMT PCB Assembly is a major part of printed circuit board mounting assembly. It is also known as surface mount technique assembly or surface mounting assembly. This is the most commonly used technology in the assembly of printed circuit boards. The SMT PCB assembly is a precise and reliable process in which components are placed and soldered on a printed circuit board. It is a cost-effective and efficient technology which offers high quality and reliable products. The SMT PCB assembly is widely used in the electronics industry for the production of complex products.

Customization:

Support and Services:

We provide technical support and service for SMT PCB Assembly products. Our technical support team is available 24/7 to answer any questions or troubleshoot any issues you may have with your product.

We understand that every project is unique and that quick and accurate support is essential. Our experienced technicians are here to help you get the most out of your SMT PCB Assembly product. Whether you need help setting up the product or if you experience an issue with the product, our technicians are here to help.

If you need any assistance with your product, please contact us via phone or email and we will be happy to help you.

Packing and Shipping:

• SMT PCB Assembly is carefully packaged in order to protect the product from any damage during shipping.
• It is shipped using insured carriers such as FedEx, UPS, or DHL.
• The package will be tracked and the customer will be notified of the shipment.
