IP Intercom 1 Layer PCB
,1 Layer PCB 0.5oz
,Flexible intercom circuit board
-
Base MaterialFR-4, Glass Epoxy, FR4 High Tg, Rohs Compliant
-
Copper Thickness1/2OZ 1OZ 2OZ 3OZ
-
Board Thickness0.4~4.0mm
-
Min. Hole Size0.01'',0.25mm.or 10 Mil
-
Min. Line Width0.006'' Or 0.15mm
-
Order Quantity1-500,000
-
Number Of Layer1,2,4,6,up To 22 Layers
-
PCB TypeHard, Flexible, Rigid-flexible
-
Max PCB Dimensions20inch*20inch Or 500mm*500mm
-
Thickness Tolerance± 10%
-
Copper Thickness Tolerance± 0.25oz
-
Solder MaskGreen, Red, White, Yellow, Blue, Black, Etc
-
Silk ScreenWhite, Yellow, Black, Or Negative, Etc
-
SMT Jointing Min. Space0201mm
-
QFP SpacePitch 0.3mm
-
PortYantian, Shekou, Hongkong
-
Place of OriginGuangdong, China
-
Model NumberOFAL0057
-
Price$20.00/pieces 1-10 pieces
-
Packaging DetailsThe goods are packed in anti-plastic bag or individual box, will be packed into corrugated packaging, made of five-layered corrugated carton.
-
Supply Ability1000 Piece/Pieces per Day
IP Intercom 1 Layer PCB 0.5oz 1oz 2oz 3oz Hard Flexible Rigid Flexible
Brand New Assembly Shenzhen Abidi Technology Ip Intercom Pcb With High Quality
Products Description
|
PCB Technical Specification
|
|
|
|
|
|
|||||
|
Order quantity
|
1-500,000
|
|
|
|
|
|||||
|
Number of layer
|
1,2,4,6,up to 22 layers
|
|
|
|
|
|||||
|
Board material
|
FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
|
|
|
|
|
|||||
|
PCB type
|
Hard, flexible, rigid-flexible
|
|
|
|
|
|||||
|
Shape
|
Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
|
|
|
|
|
|||||
|
Max PCB dimensions
|
20inch*20inch or 500mm*500mm
|
|
|
|
|
|||||
|
Board thickness
|
0.4~4.0mm
|
|
|
|
|
|||||
|
Thickness tolerance
|
± 10%
|
|
|
|
|
|||||
|
Copper thickness
|
1/2OZ 1OZ 2OZ 3OZ
|
|
|
|
|
|||||
|
Copper thickness tolerance
|
± 0.25oz
|
|
|
|
|
|||||
|
Solder mask
|
Green, red, white, yellow, blue, black, etc
|
|
|
|
|
|||||
|
Silk screen
|
White, yellow, black, or negative, etc
|
|
|
|
|
|||||
|
Silk screen min line width
|
0.006'' or 0.15mm
|
|
|
|
|
|||||
|
Surface finish
|
HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc
|
|
|
|
|
|||||
|
Min drill hole diameter
|
0.01'',0.25mm.or 10 mil
|
|
|
|
|
|||||
|
PCB cutting
|
Shear,V-score,tab-routed
|
|
|
|
|
|||||
|
PCB Assembly Capabilities
|
|
|
|
|
|
|||||
|
SMT Jointing Min. Space
|
0201mm
|
|
|
|
|
|||||
|
QFP Space
|
Pitch 0.3mm
|
|
|
|
|
|||||
|
Min. Package
|
201
|
|
|
|
|
|||||
|
Min. Size
|
2*2 inch(50*50mm)
|
|
|
|
|
|||||
|
Max. Size
|
14*22 inch(350*550mm)
|
|
|
|
|
|||||
|
Placement Precision
|
±0.01mm
|
|
|
|
|
|||||
|
Placement Precision
|
QFP, SOP, PLCC, BGA
|
|
|
|
|
|||||
|
Placement Capability
|
0805, 0603, 0402, 0201
|
|
|
|
|
|||||
|
PCB Lead time (workday(s))
|
|
|
|
|
|
|||||
|
|
Single, Double-sided
|
4 layer
|
6 layer
|
Over 8 layer
|
HDI
|
|||||
|
Sample Lead time (Normal)
|
4~5 days
|
6~7 days
|
7~8 days
|
10~12 days
|
10~12 days
|
|||||
|
Sample Lead time (Faster)
|
2~3 days
|
3~5 days
|
6 days
|
6~7 days
|
12 days
|
|||||
|
Mass production lead time
|
7~10 days
|
10~14 days
|
13-14 days
|
16 days
|
20 days
|
|||||
|
PCB Assembly Lead time
|
|
|
|
|
|
|||||
|
Sample Lead time
|
PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties.
|
|
|
|
|
|||||
|
Mass production lead time
|
PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties.
|
|
|
|
|
|||||
Company Profile
Shenzhen Oriental FastAssembly Electronic Co., Ltd.
Oriental FastAssembly Ltd. Is a PCBA manufacturer founded in year 2001, locating in Longtian district of Pingshan, Shenzhen, specializing in turnkey solution including electronics design, PCB fabrication, SMT and PCB assembly, Components sourcing, molding, metals and plastics, cables & final assembly, logistics and other value-added services etc. We’ve provide Electronic Contract Manufacturing service for products of Industrial Control, Consumer Electronics, LED/Lightning, Energy and Game Devices. Our factory is ISO9001 qualified. We have cooperated with clients around China for a long time. At the same time, our business has been expanded to Asia, Europe and America since 2005. Our core business is PCB assembly. We can provide services also including Electronic design, PCB Copy and Clone, PCB fabrication, Component sourcing, Products final assembly, Plastic Moldings & Metals, Logistics and Value-added service.
Production Line
Certifications
Cooperative
Packing & Delivery
FAQ
Q1: What files needed for PCBA quotation? A: PCB files(gerber),BOM list, XY data(pick-N-place).
Q2: MOQ and what's OFAL fatest delivery time? A:1pc. Both samples and mass production can be supported by OFAL. Bare PCB prototye: 2 layers, 24 hours 4 layers, 48 hours 6~8 layers, 72 hours PCBA(PCB Assembly): QTY<30pcs, 1 day QTY 30~100pcs, 2 days QTY 100~1000pcs, 5 days Q3: For PCB quotation, what files format do OFAL need? A: Gerber, protell 99SE, DXP, PADS 9.5, AUTOCAD, CAM350 are OK. Q4: How OFAL test PCB and PCBA boards? A: SPI, AOI, X-ray, FQC for PCBA(PCB Assembly),AOI, Fly probe testing, Test fixture testing, FQC etc for bare PCB. Q5: Can you do PCB or circuit design? A: Yes, we have design team including software, hardware and structure engineers. We can supply customized design service. Q6: Which payment terms do OFAL accept? A: TT, western union, money gram, Paypal, we also accept L/C.
