Fast Lead Time Multilayer PCB Assembly Board Thickness 0.4-3.0mm Aluminum
Multilayer PCB Assembly is an advanced 8 layer PCB manufacturing technology that provides custom PCB assembly service for FR4 multilayer PCBs. It features a minimum hole size of 0.01'', 0.25mm or 10 Mil, and a minimum trace/space of 4 Mil. The board thickness is available in a range of 0.4-3.0mm, and the copper thickness can be 1/2OZ, 1OZ, 2OZ or 3OZ. The maximum board size reaches 500mm*500mm, making it a perfect choice for various complex PCBs.
| Product Name | Technical Specifications |
|---|---|
| Multilayer PCB Assembly | Copper Thickness: 1/2OZ 1OZ 2OZ 3OZ |
| Lead Time: 7-15 Days | |
| Board Thickness: 0.4-3.0mm | |
| Min Trace/Space: 4 Mil | |
| Silkscreen Color: White,Black,Yellow | |
| Layer Count: 1-20 (6 Layer PCB, 4 Layer PCB) | |
| Min Hole Size: 0.01'',0.25mm.or 10 Mil | |
| OEM PCB Assembly | Material: FR4, High TG FR4, Halogen Free, Aluminum, Rogers, Teflon |
| Board Size: Max 500mm*500mm | |
| Layer Count: 1-20 (6 Layer PCB, 4 Layer PCB) | |
| Min Trace/Space: 4 Mil | |
| Min Hole Size: 0.01'',0.25mm.or 10 Mil |
KZX brand FR4 Multilayer PCB Assembly (model KZX2023120514) is a professional circuit board assembly service provider with certification 25020001470ROS. The minimum order quantity is 10 pieces, and the price is negotiable. It provides customer specified packing and delivery time is subject to order status. Payment terms include T/T, L/C, Paypal, western union, etc. It has 3 PCB SMT lines for production with silkscreen color white, black and yellow. The lead time is 7-15 days, and the trace/space is 4 mil. The board size can be max 500mm*500mm, and the copper thickness is 1/2OZ, 1OZ, 2OZ and 3OZ.
The Multilayer PCB Assembly will be packaged according to customer requirements. Generally, the components will be placed in an electrostatic bag or an ESD safe box, and then loaded into a carton with an inner box. The carton will have the assembly's part number, customer name, and destination address printed on it. All assemblies are shipped via express courier, and tracking numbers are provided to the customer.
Our products are sold all over the world, you can rest assured.
