White Silk Screen SMT PCB Assembly With Red Solder Mask And ICT Test
SMT PCB Assembly is a Surface Mounted Printed Circuit Board Assembly which is designed with Surface Mount Technique and Technology. It is capable of assembling components including Passive Components, Connectors, ICs, BGA and QFN. The materials used for SMT PCB Assembly include FR-4, FR-1, CEM-1, CEM-3, Aluminum and Rogers. The surface finish of SMT PCB Assembly includes HASL, ENIG, OSP, Immersion Silver and Immersion Tin. To ensure the quality of the SMT PCB Assembly, it is tested by AOI, X-Ray, Flying Probe, ICT and FCT.
| Parameter | Value |
|---|---|
| Product Type | Surface Mount PCB Assembly, Surface Mounted Printed Circuit Board Assembly, Printed Circuit Board Assembly |
| Material Type | FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers |
| Silk Screen Color | White, Black, Yellow |
| Components | Passive Components, Connectors, ICs, BGA, QFN |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Immersion Tin |
| Board Thickness | 0.2-6.0mm |
| Test | AOI, X-Ray, Flying Probe, ICT, FCT |
| Solder Mask Color | Green, Blue, White, Black, Yellow, Red |
KZX is a leading provider of Printed Circuit Board Mounting Assembly and Surface Mount Technique Assembly services.
The KZX SMT PCB Assembly has a model number of KZX2023120502 and is certified to 25020001470ROS. The board thickness ranges from 0.2 to 6.0mm, and the surface finishes that can be used include HASL, ENIG, OSP, Immersion Silver, and Immersion Tin. The material types include FR-4, FR-1, CEM-1, CEM-3, Aluminum, and Rogers. The silk screen colors available are white, black, and yellow.
KZX offers the minimum order quantity of 10 pieces and is willing to negotiate prices. The packaging details can be customized to the customer's specification. Delivery time is subject to order status, and payment terms include T/T, L/C, Paypal, and Western Union. KZX's supply ability is 3 PCB SMT lines.
KZX's SMT PCB Assembly services are of the highest quality and provide the most efficient Electronic Component Mounting for a range of applications. With a wide range of Surface Finish options, Board Thickness varieties, and Material Types, KZX provides the best Electronic Manufacturing Services for all your needs.
We provide comprehensive technical support and services for SMT PCB Assembly. Our team of experienced engineers and technicians are available to answer any questions and provide assistance with product design, assembly, and production.
We offer a variety of services to ensure the highest quality and reliability of your PCBs. Our services include:
We also provide a wide range of technical support services, such as providing guidance on design, assembly, and testing processes, as well as helping to optimize production processes.
We are committed to providing the highest level of customer service and satisfaction. If you have any questions or need assistance with your SMT PCB Assembly project, please don't hesitate to contact us.
SMT PCB Assembly Packaging and Shipping:
The SMT PCB Assembly product will be packaged in a suitable container and shipped using a reputable courier service. The box should be large enough to ensure the product is secure during transit and to protect it from potential damage. The box should also include any necessary documentation, such as instructions for assembly and/or use. The courier service should provide tracking information and delivery updates so the customer can track its progress.
Our products are sold all over the world, you can rest assured.
