BGA Components Integrated Into White Silk Screen Surface Mount Technology Assembly
SMT PCB Assembly is a process of surface mounting components to a printed circuit board (PCB) for efficient electrical connections. It includes a wide range of components from passive components, connectors, integrated circuits (ICs), ball grid array (BGA) and quad flat no-lead (QFN) packages, all of which need to be placed and soldered onto a PCB. The PCBs come in a variety of thicknesses ranging from 0.2-6.0mm. After components are placed on the PCB, a variety of tests such as automated optical inspection (AOI), X-ray inspection, flying probe testing, in-circuit testing (ICT) and functional testing (FCT) are conducted to ensure the functionality and reliability of the PCB assembly. The PCB assembly is then completed with various surface finishes such as HASL (Hot Air Solder Leveling), ENIG (Electroless Nickel Immersion Gold), OSP (Organic Solderability Preservative), immersion silver and immersion tin. The SMT PCB Assembly process requires expertise and advanced equipment to ensure the highest level of quality and reliability.
| Parameters | Value |
|---|---|
| Test | AOI, X-Ray, Flying Probe, ICT, FCT |
| Product Type | SMT PCB Assembly |
| Silk Screen Color | White, Black, Yellow |
| Components | Passive Components, Connectors, ICs, BGA, QFN |
| Material Type | FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Immersion Tin |
| Board Thickness | 0.2-6.0mm |
| Solder Mask Color | Green, Blue, White, Black, Yellow, Red |
| Printed Circuit Board Assembly | Yes |
| Surface Mounting Assembly | Yes |
| Surface Mount Technique Assembly | Yes |
KZX SMT PCB Assembly, model number KZX2023120502, is a high-quality surface mounted electronic assembly product certified by 25020001470ROS. It is manufactured by KZX, a leading brand in the industry, with a minimum order quantity of 10 pieces. The price is negotiable, and customer-specified packing is available. Delivery time is subject to order status, and payment terms include T/T, L/C, Paypal, and western union. With 3 PCB SMT lines, KZX can provide a maximum of 3 Surface Mounted Assemblies with superior production capacity. The product is made from high-quality materials, including FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers, and others. It is also equipped with a variety of components, such as passive components, connectors, ICs, BGAs, QFNs, and more. The silk screen color is available in black, white, and yellow, and the solder mask color comes in green, blue, white, black, yellow, and red.
The KZX SMT PCB Assembly is designed for the surface mount technology (SMT) industry. It is widely used in consumer electronics, telecommunications, automotive electronics, medical electronics, aerospace electronics, industrial electronics, and other industries. It is applicable for a range of products, such as computers, tablets, smart phones, digital cameras, and other electronic products. It features high precision, high speed, and high reliability, making it perfect for businesses that value quality, performance, and cost-effectiveness.
KZX SMT PCB Assembly is the perfect choice for businesses looking for an efficient and reliable surface mounted assembly solution. With its high quality materials and components, excellent production capacity, and competitive price, it offers the best value for money and ensures your satisfaction. Whether you’re looking for a high-end product or a cost-effective solution, KZX will have the right product for you.
KZX offers custom Surface Mount Technique Assembly (SMT) and Printed Circuit Board Assembly (PCBA) services with the lowest possible cost. We can provide one-stop service from components procurement, assembly, soldering, printing, testing to packaging. Our advanced SMT and PCBA lines, with the help of our experienced engineers, enable us to provide you with high-quality products with faster turnaround time.
Keywords: Surface Mount Technique Assembly, Printed Circuit Board Assembly, Printed Circuit Board Mounting Assembly
We provide comprehensive technical support and services to ensure your SMT PCB assembly process is successful. Our experienced engineers can provide you with professional advice on selecting the right equipment and materials to effectively and accurately assemble your circuit boards. We offer a variety of services including:
We believe in offering our customers the highest quality services and support. Our team of specialists is available to answer your questions and provide you with the best possible solutions. Contact us today to learn more about our SMT PCB Assembly services.
SMT PCB Assembly Packaging and Shipping:
The SMT PCB Assembly is packaged in anti-static bags or foam-in-place packaging and then placed in a box. The box is then bubble wrapped and placed in a larger box for shipping. The larger box is then sealed and labeled with the appropriate shipping information.
Our products are sold all over the world, you can rest assured.
