Black Solder Mask Color Surface Mount PCB Assembly With Immersion Tin Surface Finish
SMT PCB Assembly is the process of assembly of Printed Circuit Board (PCB) components that use Surface Mount Technology (SMT). This process involves mounting components such as passive components, connectors, integrated circuits (ICs), ball grid arrays (BGAs), and quad flat no-leads (QFNs) onto a printed circuit board. The components are then soldered onto the board via a high-speed automated process. The surface finish of the boards can be done via processes such as Hot Air Solder Leveling (HASL), Electroless Nickel Immersion Gold (ENIG), Organic Solderability Preservative (OSP), immersion silver, and immersion tin. To ensure a good quality product, various tests are performed such as Automated Optical Inspection (AOI), X-ray inspection, Flying Probe, In-Circuit Test (ICT), and Functional Circuit Test (FCT). The boards also have solder mask colors such as green, blue, white, black, yellow, and red. SMT PCB Assembly is a comprehensive process that requires the use of state-of-the-art tools and technologies to deliver a high-quality product to the customer.
Parameter | Value |
---|---|
Solder Mask Color | Green, Blue, White, Black, Yellow, Red |
Board Thickness | 0.2-6.0mm |
Surface Finish | HASL, ENIG, OSP, Immersion Silver, Immersion Tin |
Material Type | FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers |
Silk Screen Color | White, Black, Yellow |
Components | Passive Components, Connectors, ICs, BGA, QFN |
Product Type | SMT PCB Assembly |
Test | AOI, X-Ray, Flying Probe, ICT, FCT |
KZX's SMT PCB Assembly is an ideal choice for many applications that require reliable performance and accuracy. The model number KZX2023120502 is specially designed to provide superior surface mounted printed circuit board assembly. This product is certified by 25020001470ROS and has a minimum order quantity of 10 pieces. The price is negotiable and customers can specify their own packaging. Delivery time is subject to the order status and payment terms can be T/T, L/C, Paypal, western union, etc. It has a supply ability of 3 PCB SMT lines and the product type is surface mounted printed circuit board assembly. The test includes AOI, X-Ray, Flying Probe, ICT, FCT. The solder mask color is available in green, blue, white, black, yellow, and red. The surface finish can be HASL, ENIG, OSP, immersion silver, immersion tin and the materials used are FR-4, FR-1, CEM-1, CEM-3, aluminum, and rogers. KZX's SMT PCB Assembly is a reliable and efficient way to achieve the best quality and accuracy for your surface mount technique assembly.
KZX Printed Circuit Board Assembly (Model Number: KZX2023120502) is produced by KZX, with certification from 25020001470ROS. This SMT PCB Assembly is widely used in many industries.
KZX Printed Circuit Board Assembly is highly reliable and cost effective. It is surface mount technology assembly, which is widely used in many industries. This Printed Circuit Board Assembly is made with high quality materials and advanced technology, with excellent performance.
SMT PCB Assembly provides technical support and service to ensure the highest performance of all products. Our technical support team is highly experienced and knowledgeable, and will assist you in resolving any issues you encounter with your product. We offer phone and email support, as well as on-site visits if needed. Our goal is to ensure that your product is working properly and meeting your needs. We also provide training and resources to help you get the most out of your product.
SMT PCB Assembly Packaging and Shipping:
The SMT PCB Assembly products will be packaged in custom-made anti-static bags and placed in cardboard boxes. Each box will have a label with all the necessary information, such as part numbers, product description, quantity, etc. The boxes will be sealed and secured with bubble wrap. The boxes will then be shipped via courier service, such as FedEx or UPS, to the customer's address.
