Durable SMT PCB Assembly With AOI Test In CEM-1 Material For High-Performance
Surface Mounted Printed Circuit Board Assembly, or SMT PCB Assembly, is a highly complex and precise process of creating printed circuit boards. It involves mounting components to the board using surface mount technology (SMT), which is a method for placing electronic components onto the surface of a printed circuit board. The components are soldered and secured using special adhesives. The components are then tested to ensure that they are properly placed and securely mounted.
SMT PCB Assembly is used in a wide variety of applications, from consumer electronics to medical devices, automotive, and aerospace. It requires a highly specialized set of materials, such as FR-4, FR-1, CEM-1, CEM-3, aluminum, and Rogers, to create a strong and reliable board. The board thickness can range from 0.2 to 6.0mm, and the assembly can be tested using various methods, such as AOI, X-Ray, Flying Probe, ICT, and FCT. The assembly can also be printed with silk screen colors, such as white, black, and yellow.
Surface Mount PCB Assembly is a complex and intricate process that requires great attention to detail and precision. It is a great way to create high-quality printed circuit boards that are reliable and long-lasting.
| Product Type | SMT PCB Assembly |
|---|---|
| Components | Passive Components, Connectors, ICs, BGA, QFN |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Immersion Tin |
| Test | AOI, X-Ray, Flying Probe, ICT, FCT |
| Board Thickness | 0.2-6.0mm |
| Solder Mask Color | Green, Blue, White, Black, Yellow, Red |
| Silk Screen Color | White, Black, Yellow |
| Material Type | FR-4, FR-1, CEM-1, CEM-3, Aluminum, Rogers |
| Keywords | Surface Mount Technique Assembly, Surface Mount PCB Assembly, Surface Mounted Assembly |
KZX SMT PCB Assembly, model KZX2023120502, is an advanced surface mount technique assembly ideal for building complex circuitry. It is certified (25020001470ROS) and available in minimum order quantity of 10 pieces. The components used in KZX SMT PCB Assembly include passive components, connectors, ICs, BGA, QFN, and more. The board thickness of the assembly ranges from 0.2 to 6.0mm. The surface mount assembly also has various silk screen colors, including white, black and yellow, and solder mask colors, including green, blue, white, black, yellow, and red.
The KZX SMT PCB Assembly is affordable and comes with customer specified packing. Payment terms include T/T, L/C, Paypal, western union, etc. Delivery time is subject to order status. The assembly is manufactured in Guangdong, China and comes with a supply ability of 3 PCB SMT lines.
KZX SMT PCB Assembly is a great choice for businesses and individuals looking to build complex circuitry. It is reliable, efficient, and cost-effective, making it ideal for a wide range of applications. With its advanced surface mount technology, KZX SMT PCB Assembly is a great choice for any project that requires complex circuitry.
SMT PCB Assembly
Brand Name: KZX
Model Number: KZX2023120502
Place of Origin: Guangdong, China
Certification: 25020001470ROS
Minimum Order Quantity: 10 piece
Price: Price negotiation
Packaging Details: Customer specified packing
Delivery Time: Subject to order status
Payment Terms: T/T, L/C,Paypal,western union etc
Supply Ability: 3 PCB SMT lines
Board Thickness: 0.2-6.0mm
Components: Passive Components, Connectors, ICs, BGA, QFN
Silk Screen Color: White, Black, Yellow
Solder Mask Color: Green, Blue, White, Black, Yellow, Red
Product Type: SMT PCB Assembly
Printed Circuit Board Assembly, Surface Mount Technology Assembly, Surface Mount PCB Assembly
We provide technical support and service for SMT PCB Assembly. Our experienced staff can provide you with first-class assistance and advice on every aspect of the SMT PCB Assembly process, from design to prototyping to volume production.
Our technical support team can assist you with:
We are committed to providing our customers with the highest level of service and support. We are always here to help you with any questions or issues you may have. Please do not hesitate to contact us for more information.
Our products are sold all over the world, you can rest assured.
