High-Performance Surface Mount PCB Assembly With 1oz Copper Thickness
SMT PCB Assembly is a specialized type of circuit board assembly that uses surface mount technology (SMT). This process is used for designing and assembling small circuit boards with high levels of accuracy and precision. The process includes the use of copper thickness of 1oz, the minimum line spacing of 0.1mm, the minimum hole size of 0.2mm, and the assembly type of SMT. This assembly process is used for two-layer circuit boards and is ideal for high-density applications. The surface mounting technique of this assembly process is highly reliable and ensures a perfect and secure connection between the components and the circuit board. This process is ideal for creating high-performance circuit boards with greater efficiency.
| Parameter | Value |
|---|---|
| Product | Surface Mount PCB Assembly |
| Material | FR4 |
| Assembly Type | SMT |
| Components Type | SMD |
| PCB Layer | 2-Layer |
| Min Line Spacing | 0.1mm |
| Min Line Width | 0.1mm |
| Min Hole Size | 0.2mm |
| Copper Thickness | 1oz |
SMT PCB Assembly is a type of Surface Mounted Assembly that involves mounting Printed Circuit Board components onto the Surface Mounted Printed Circuit Board. It is a complex process that requires precision and accuracy with regards to the material, copper thickness, PCB layer, and the size of the smallest hole which is 0.2mm. The material used to create the PCB is usually FR4, and the thickness of the copper is usually 1oz. The number of layers of PCB boards used for this type of assembly varies, but usually it is a 2-layer PCB. SMT PCB Assembly is often used in a variety of applications such as automotive, industrial, medical, and consumer electronics, due to its reliability and accuracy.
At ABC Company, we understand that you value quality when it comes to SMT PCB Assembly. Our services are designed to meet your exacting standards, utilizing the latest Surface Mount Technique Assembly techniques. Our Surface Mount Technology Assembly is tailored to meet your needs, from Surface Mount PCB Assembly to components type. We offer SMD with min line width of 0.1mm and copper thickness of 1oz, all on FR4 material.
We provide comprehensive technical support and service for SMT PCB Assembly. Our team of highly skilled engineers and technicians are available to assist you with your project from the initial design stage to the final assembly stage. We can provide advice on best practices, design guidelines, component selection, prototyping, testing, and troubleshooting. Our engineers are experienced in using the latest software and hardware tools to ensure the best results and the highest quality product.
We also provide consultation services to help you with the entire process, from the initial concept to the final production stage. We can help you optimize the design for cost, performance, and manufacturability. Our team can also provide technical support and guidance to ensure that your project is completed on time and within budget.
Our SMT PCB assembly services include component placement, soldering, testing, and inspection. We use the latest technology to ensure that all our products meet the highest quality standards. We also provide after-sales support to ensure that our customers are satisfied with their purchase.
SMT PCB Assembly Packaging and Shipping
Our products are sold all over the world, you can rest assured.
