High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly

High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly

Products - 2 Layers PCB
  • High Light

    High End 2 Layers PCB

    ,

    2 Layers PCB 1.0mm

    ,

    0.5oz Printed PCB Assembly

  • Base Material
    FR-4
  • Copper Thickness
    1/2OZ
  • Board Thickness
    1.0mm
  • Min. Line Spacing
    4 Mil
  • Surface Finishing
    HASL
  • Order Quantity
    6000
  • Number Of Layer
    1 Layer
  • PCB Type
    Hard
  • Max PCB Dimensions
    20inch*20inch Or 500mm*500mm
  • Thickness Tolerance
    ± 10%
  • Copper Thickness Tolerance
    ± 0.25oz
  • Solder Mask
    Green, Red, White, Yellow, Blue, Black, Etc
  • Silk Screen
    White, Yellow, Black, Or Negative, Etc
  • SMT Jointing Min. Space
    0201mm
  • QFP Space
    Pitch 0.3mm
  • Place of Origin
    Guangdong, China
  • Brand Name
    OFAL
  • Model Number
    IM7.2
  • Minimum Order Quantity
    1
  • Price
    0.58/pieces 1-20 pieces
  • Packaging Details
    The goods are packed in anti-plastic bag or individual box, will be packed into corrugated packaging, made of five-layered corrugated carton.
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    10000 Piece/Pieces per Day

High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly

  • High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly
  • High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly
  • High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly
  • High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly
  • High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly
  • High End 2 Layers PCB Intercom Module Electronics Printed PCB Assembly
Get Price Contact Now
Products Description




PCB Technical Specitication

Board Material FR4
Order quantity any quantity available
Number of layer4 1 layer
Shape Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
Max PCB dimensions 20 inch*20 inch or 500mm*500mm
Board thickness 1.0mm, customized from 0.4mm up to 4mm
Thickness tolerance 士10%
Copper thickness 10Z, 2OZ
tolerance +0.25oz
Solder mask Green, black, etc
Silk screen White, yellow, black, or negative, etc
Silk screen min line width 0.006 or 0.15mm
Surface fnish HASL, Nickle, lmm Gold, Imm Tin, Imm Silver, OSP etc
Min drill hole diameter 0.01"0.25mm.or 10 mil
PCB cutting Shear,V-score,tab-routed
Application LCD screen MCU control board
Industry Climate Control Solutions







PCB Assembly Capabilities

SMT Jointing Min. Space 0201mm
QFP Space Pitch 0.3mm
Min. Package 201
Min. Size 2*2 inch(50*50mm)
Max. Size 14*22 inch(350*550mm)
Placement Precision +0.01mm
Placement Precision QFP.SOP.PLCC,BGA
Placement Capability 0805.0603.0402.0201
Quality Control Visual Inspection, FAI, AOI, X-RAY, Functional testing





PCB Lead time workday(s)



  Single, Double-sided 4 layer 6 layer Over 8 layer HDI
Sample Lead time (Normal) 4~5 days 6~7 days 7~8 days 10~12 days 10~12 days
Sample Lead time (Faster 2~3 days 3~5 days 6 days 6~7 days 12 days
Mass production lead time 7~10 days 10~14 days 13-14 days 16 days 20 days



PCB Assembly Lead time
Sample Lead time PCB Fab+Components Sourcing+PCBA= 7~15 days according to level difficulties
Mass production lead time PCB Fab+Components Sourcing+PCBA=14~28 daysaccording to QTY and level difficulties.
